PLC IM303 – сontrôleurs logiques programmables

IM303 PLC, with integrated I/O, x86-200, 128 MB RAM, 16 kB FRAM, 1 GB flash, 1 insert slot for interface modules, 1 x USB, 1 x RS-232, 1 x Ethernet, 14 digital inputs, 24 VDC, sink, 4 digital inputs, 2 µs, 24 VDC, sink, 4 digital outputs, 24 VDC, 0.5 A, source, 4 digital outputs, 2 µs, 24 VDC, 0.2 A, 4 digital inputs/outputs, 24 VDC, 0.5 A, 2 analog inputs ±10 V or 0 to 20 mA / 4 to 20 mA, 1 x Pt1000, 3 x terminal block, slot cover end cover plate (right) included.

IM303 PLC, with integrated I/O, x86-200, 128 MB RAM, 16 kB FRAM, 1 GB flash, 1 insert slot for interface modules, 2 x USB, 1 x RS-232, 1 x CAN bus interface, 1 x POWERLINK, 1 x Ethernet, 14 digital inputs, 24 VDC, sink, 4 digital inputs, 2 µs, 24 VDC, sink, 4 digital outputs, 24 VDC, 0.5 A, source, 4 digital outputs, 2 µs, 24 VDC, 0.2 A, 4 digital inputs/outputs, 24 VDC, 0.5 A, 2 analog inputs ±10 V or 0 to 20 mA / 4 to 20 mA, 1 x Pt1000, 3 x terminal block, slot cover end cover plate (right) included.

IM303 PLC, with integrated I/O, x86-200, 128 MB RAM, 16 kB FRAM, 1 GB flash, 1 insert slot for interface modules, 2 x USB, 1 x RS-232, 1 x CAN bus interface, 1 POWERLINK, 1 x Ethernet, reACTION Technology, 14 digital inputs, 24 VDC, sink, 4 digital inputs, 2 µs, 24 VDC, sink, 4 digital outputs, 24 VDC, 0.5 A, source, 4 digital outputs, 2 µs, 24 VDC, 0.2 A, 4 digital inputs/outputs, 24 VDC, 0.5 A, 2 analog inputs ±10 V or 0 to 20 mA / 4 to 20 mA, 1 x Pt1000, 3 x terminal block, slot cover end cover plate (right) included.

IM303 PLC, with integrated I/O, x86-400, 256 MB RAM, 32 kB FRAM, 2 GB flash, 1 insert slot for interface modules, 2 x USB, 1 x RS-232, 1 x CAN bus interface, 1 x POWERLINK interface, 1 x Ethernet, 14 digital inputs, 24 VDC, sink, 4 digital inputs, 2 µs, 24 VDC, sink, 4 digital outputs, 24 VDC, 0.5 A, source, 4 digital outputs, 2 µs, 24 VDC, 0.2 A, 4 digital inputs/outputs, 24 VDC, 0.5 A, 2 analog inputs ±10 V or 0 to 20 mA / 4 to 20 mA, 1 x Pt1000, 3 x terminal block, slot cover end cover plate (right) included.

IM303 PLC, with integrated I/O, x86-400, 256 MB RAM, 32 kB FRAM, 2 GB flash, 1 insert slot for interface modules, 2 x USB, 1 x RS-232, 1 x CAN bus interface, 1 x POWERLINK interface, 1 x Ethernet, reACTION Technology, 14 digital inputs, 24 VDC, sink, 4 digital inputs, 2 µs, 24 VDC, sink, 4 digital outputs, 24 VDC, 0.5 A, source, 4 digital outputs, 2 µs, 24 VDC, 0.2 A, 4 digital inputs/outputs, 24 VDC, 0.5 A, 2 analog inputs ±10 V or 0 to 20 mA / 4 to 20 mA, 1 x Pt1000, 3 x terminal block , slot cover end cover plate (right) included.
